ARTWORK GUIDELINES
FTP SITE GUIDELINES
ACCEPTABLE FILE FORMATS
FONT SPECIFICATIONS
RESOLUTION
VINYL CUT GRAPHICS
SUBMITTING ART FILES
MURALS &
POPUP GRAPHICS
COLOR SPECIFICATIONS
WEB BROWSER FTP SOFTWARE
High quality PDF (preferred)
Illustrator CC or below
Photoshop CC or below
InDesign CC or below (not preferred)
High quality, editable PDF’s, Illustrator and
Photoshop files are preferred, as they are more
suitable for large format printing. Art time will
be charged if files need to be fixed or altered
to meet guidelines. When sending files, please
be sure to include all support art (fonts, linked
images, etc.).
Please note that Illustrator special effects such
as glows, transparencies or drop shadows are
not recommended. These effects sometimes
have unpredictable results when printing
Photoshop is preferred when using such
special effects.
Fonts must be converted to outlines. If fonts are not
created to outlines, please provide Macintosh or
TruType fonts. If changes need to be made in the file,
please provide the fonts and a version of the file with
editable type.
All raster files (either print files or linked files)
must be at 100-120 pixels per inch at 100%.
All graphics produced require specific bleeds.
Below is a general outline for the required bleeds.
• MURAL POPUP FILES:
1/2" bleed around the perimeter
• COLLAPSIBLE FABRIC DISPLAYS,
TENSION FABRIC BACKWALLS AND
EXTRUSION FRAME BANNERS
AND BACKWALLS:
2” bleed around the perimeter. Please keep all
logos, type, and critical information at least 2”
in from the visual edge of the graphic.
• FABRIC STRUCTURES:
5” bleed around the perimeter.
• BANNER STAND GRAPHICS:
Each product has specific bleed requirements.
Please refer to the graphic template for specific
information. Different printing processes may
require different bleeds. All banner stand
graphics printed on Resilience will require an
extra 1” bleed around the perimeter.
• CUSTOM DYE SUB FLAG GRAPHICS:
2” bleed left & right sides, 4” bleed at the
top & bottom.
• ORBITAL EXPRESS™ TRUSS GRAPHICS - UV:
1/2” bleed around the perimeter.
• ORBITAL EXPRESS™ TRUSS GRAPHICS -
DYE SUB:
2” bleed around the perimeter.
• CUSTOM CONTOUR CUT UV GRAPHICS:
1/2” bleed around the perimeter.
• CUSTOM DYE SUB GRAPHICS:
2” bleed around the perimeter.
• CUSTOM DYE SUB GRAPHICS
EXCEEDING 160":
5” bleed around the perimeter.
Artwork must be set up as a vector file with fonts
created to outlines for all cut vinyl. Please specify
every color number for solid color vinyl or PMS
color for adhesive back and cut vinyl.
Files are accepted via Email (up to 10MB),
FTP site, DVD and CD or File Transfer site
such as WeTransfer or Hightail.
Files can be uploaded to:
Please reference the FTP site guidelines
for more information.
Popup mural files must be built as one file.
Please note where panel breaks are located and
try to minimize the amount of type that crosses
over the panel breaks.
We provide an FTP site to upload files quickly and at
no additional cost. The site can be accessed through
a web browser or an FTP software such as FETCH.
Please read below for detailed instructions.
4. When your upload is complete, please place the order with your sales
representative and include any critical file information.
Address:
no user ID
no password
choose the anonymous login option
Address: ftp.handbookart.com
no user ID
no password
1. Please place all art files in a folder. Please name the
folder by client name and purchase order number.
2. Compress files using software such as WinZip or
Stuffit. All compressed files must be under 500MB.
3. Access the FTP by web browser or FTP software.
Please provide all vector files (Illustrator & InDesign)
in CMYK format. Please supply all raster artwork
(Photoshop files, jpgs, tiffs) in RGB format for the
most accurate color output. Please provide a hard
copy proof of the files being printed for color accuracy
and a PDF layout for file layout accuracy.
If Pantone colors need to be matched please specify
on purchase order or hard copy reference. All critical
Pantone colors need to be called out in the file as solid
coated swatches. If multiple Pantone swatches are
used in the file, all will be matched to solid coated
unless otherwise specified.
If color matching to existing graphics, we will need
those back to review. Please contact your sales
representative for a case number.
Please feel free to submit catalogs, brochures, printed
proofs, etc. to use as a color reference. Please provide
a layered file for Photoshop files if color matching is
required. Art time may be charged to correct flattened
Photoshop files.
We guarantee color matching on all hard copy proofs,
specified Pantone colors and client-supplied hard copy
proofs. Orders without indication of Pantone colors,
supplied proofs or requested hard copy proofs are
NOT guaranteed for color.
BLEED SPECIFICATIONS
ISO 14001 : 2004
ISO 9001 : 2008
UPLOAD ART TO
